Product Description

What is the 530W to 550W Solar Photovoltaic Panel?

The 530W to 550W Solar Photovoltaic Panel from Suntech Power is a cutting-edge solar solution designed to meet a wide range of energy needs. Featuring monocrystalline bifacial half-cell technology, it delivers peak power output between 530W and 550W, with an impressive 21.3% conversion efficiency. Its bifacial design captures additional energy from the rear side, boosting energy yield by up to 25% in optimal conditions.

Features of the 530W to 550W Solar Photovoltaic Panel

· High Efficiency: Peak power output of 530W to 550W, with a conversion efficiency of 21.3%.

· Bifacial Design: Increases energy generation by up to 25% by utilizing both sides of the panel.

· Durability: 2.0mm tempered glass, IP68-rated junction box, and robust construction for harsh environments.

· Wide Operating Range: Temperature range of -40°C to +85°C, mechanical load capacity of 2400Pa negative pressure and 5400Pa positive pressure.

· Low-Light Performance: Excellent performance in low-light conditions due to low-temperature coefficients.

Applications of the 530W to 550W Solar Photovoltaic Panel

· Residential Installations: Ideal for home energy systems, offering reliable and efficient solar power.

· Commercial & Industrial Use: Perfect for large-scale installations in commercial and industrial applications.

· Extreme Environments: Suitable for use in harsh climates such as deserts, coastal areas, and agricultural environments.

Price of the 530W to 550W Solar Photovoltaic Panel

The price is based on EXW (Ex Works) terms and can vary depending on the supplier, order quantity, and market conditions. To get the most accurate pricing, please request a quote from a reputable energy storage supplier. Final costs may fluctuate due to raw material price changes and exchange rates.

If you are looking for 530W to 550W Solar Photovoltaic Panel and want to know more about the technical information, please feel free to contact Dagong ESS.

Specification	STC	STPXXXS-C72/Pmh+
STC Peak Power (Pmax)	550W	545W, 540W, 535W, 530W
Optimal Operating Voltage (Vmp)	42.05V	41.87V, 41.75V, 41.57V, 41.39V
Optimal Operating Current (Imp)	13.08A	13.02A, 12.94A, 12.87A, 12.81A
Open Circuit Voltage (Voc)	49.88V	49.69V, 49.54V, 49.39V, 49.24V
Short Circuit Current (Isc)	14.01A	13.96A, 13.89A, 13.83A, 13.76A
Module Conversion Efficiency	21.30%	21.10%, 20.90%, 20.70%, 20.50%
Operating Temperature Range	-40 °C to +85 °C	-40 °C to +85 °C
Maximum System Voltage	1500 V DC (IEC)	1500 V DC (IEC)
Maximum Fuse Rating	25 A	25 A
Power Tolerance	0/+5 W	0/+5 W
STC Condition	Irradiance 1000 W/m², Module Temperature 25°C, AM=1.5	Power tolerance is +/- 3%. Consult Suntech for mounting system information.

Specification	NMOT	STPXXXS-C72/Pmh+
NMOT Peak Power (Pmax)	415.0W	411.5W, 408.0W, 404.3W, 400.6W
Optimal Operating Voltage (Vmp)	38.9V	38.7V, 38.6V, 38.4V, 38.2V
Optimal Operating Current (Imp)	10.67A	10.63A, 10.58A, 10.53A, 10.47A
Open Circuit Voltage (Voc)	46.9V	46.7V, 46.5V, 46.4V, 46.3V
Short Circuit Current (Isc)	11.22A	11.18A, 11.13A, 11.08A, 11.02A
NMOT Condition	Irradiance 800 W/m², Ambient Temperature 20°C, AM=1.5, Wind Speed 1 m/s	Power tolerance is +/- 3%. Consult Suntech for mounting system information.

Specification	5%	15%	25%
STC Peak Power (Pmax)	567W	621W	675W
Optimal Operating Voltage (Vmp)	41.8V	41.8V	41.9V
Optimal Operating Current (Imp)	13.59A	14.88A	16.18A
Open Circuit Voltage (Voc)	49.5V	49.5V	49.6V
Short Circuit Current (Isc)	14.48A	15.86A	17.24A
Module Conversion Efficiency	21.90%	24.00%	26.10%

Specification	Value
Nominal Module Operating Temperature (NMOT)	42 ± 2 °C

Specification	Value
Solar Cell Type	Monocrystalline Silicon, 182 mm
Number of Cells	144 (6 * 24)
Module Dimensions	2279*1134*30mm (89.7*44.6 *1.2 in)
Weight	32.8 kg (72.3 lbs)
Glass (Front/Back)	2.0 mm + 2.0 mm (0.079 in + 0.079 in), Semi-Tempered Glass
Junction Box	IP68
Output Cable	4.0 mm², Negative (-) 350 mm / Positive (+) 160 mm or customized length
Connector	MC4 EVO2, Cable01S
Bifacial Factor	70 ± 5%
